FU-ISC-M9 UHF RFID Smart Ticket Cabinet

Overview

Product features

The cabinet is equipped with an RFID device featuring self-developed anti-collision algorithm technology. It can automatically count and verify the receipts and documents inside the cabinet in real time and transmit the data to the background server. It can display the borrowing and returning records in real time, ensuring that the records are 100% consistent with the physical items.

File location function

The cabinet is equipped with a built-in ticket positioning sensor device. When the documents inside the cabinet need to be taken out or placed in, it can automatically identify and locate the current position of the documents, and give audible and visual prompts. It can also be used for search and location, making it convenient to obtain the documents.

Positioning data binding

The cabinet is equipped with a positioning logic determination function. When performing the operation of placing bill files, the real-time position is bound with the current bill data, and the current storage status of the grid can be determined. The number of Spaces and the storage quantity in the cabinet can be displayed in real time.

Alarm/reminder function

The cabinet is equipped with an alarm/reminder function, which determines the current storage status of the grid and provides corresponding sound and light prompts. If the system self-checks and finds that the inventory data is inconsistent, it will issue an alarm prompt.

System function

System function	Function Introduction
Human-computer interaction interface	The cabinet door is embedded with a 12.1-inch LCD touch screen, which can be operated and interacted through the system interface to view file storage and door opening log records, etc.
System Management Platform	The system can monitor and record in real time the actions of the cabinet door (opening and closing) in detail, and confirm the operation, record the time, file changes, etc. through the background management platform.
Access control card reader	It is used to read the information of RFID access control cards as one of the rules for determining the door opening.
Enter the password to unlock	Users can set the password for the cabinet door switch. After verification is successful, the cabinet door can be opened.
Fingerprint collection and recognition	The user's fingerprint is identified through the fingerprint collector and verified to open the cabinet door. The cabinet door is opened by pulling the handle according to the voice prompt.
Cabinet door opening and closing control	The main controller controls the opening and closing of the filing cabinet door by comprehensively detecting the input password, access control card and fingerprint, and outputs a switch signal to the switch controller according to the set combination door opening and closing rules.
Real-time monitoring and inventory taking	The main controller conducts regular inventory checks on the tags inside the bill cabinet and immediate inventory checks when the cabinet door is closed through the RFID read-write controller. At the same time, it stores the inventory information in real time and uploads it to the background management system.
Remote inventory taking	The user sends inventory instructions to the main controller through the background management system. After receiving the instructions, the main controller immediately conducts the inventory and returns the inventory information to the background management system.
File location function	The current file retrieval/placement status is automatically determined through the positioning sensor device. The position of the file can be located through the indicator light (with a left-right error of 1cm), and the position data is bound according to the logical function.
Power-off data record	During the process of file placement, the current position triggered at the moment of power failure is recorded. After the power is restored, the reading device is triggered to perform positioning.
Capacity of the filing cabinet	The filing cabinet can identify at least 2,000 documents 100%. The documents are stored in file bags and their thickness is not fixed.
Sound and light/alarm prompt	Determine the status of the compartments inside the cabinet and provide audible and visual prompts. If the inventory data is inconsistent during the system self-check, an alarm sound can be triggered through a professional alarm device.
The function of drawing electricity from the municipal power supply	It can work directly on the municipal power supply without the need to connect an additional transformer.

Specifications

Structural features

The structural process adopts military-grade manufacturing standards, which are safe and reliable. Conduct thorough design analysis on every structural detail to ensure that the customer's requirements are met.

1. The inner layer board spacing of the cabinet is available in 5mm or 10mm, and can be customized according to requirements.

2. High-quality thickened steel plates (1.5mm to 2.0mm), with high hardness and reliable quality;

3. Enhanced anti-picking device, safe and reliable;

4. Safe and phosphorus-free electrostatic powder coating with high durability;

5. The bottom is designed with universal wheels for convenient handling.

6. Install a fixing device at the bottom to ensure stable placement and prevent toppling.

Application

This product is suitable for government agencies, public institutions, enterprises, financial companies and other occasions where personnel certificates need to be managed in a standardized manner.
